4. UV visual positioning system

CCD visual positioning equipped with UV flatbed printer, no need for fixtures to be placed arbitrarily, no need for manual positioning, products to be placed arbitrarily, automatic scanning, positioning and printing

Solve the problem of difficult placement and alignment of small and irregular products during printing

The camera can accurately and quickly recognize product contours, achieve synchronous data transmission, print accurately, have high color reproduction, and have more delicate pattern effects

Subpixel detection algorithm

Subpixel detection algorithm, effectively dealing with various handicrafts, badges, accessories, digital products, shoe materials, clothing products, etc

Ultra clear wide scanning camera

Ultra clear wide-angle scanning camera, in-depth research on leading graphic image recognition and positioning algorithms

Matching pattern

Support import and template matching

Product features: Wide scanning camera+visual positioning printing system

1:1 image output, matching multiple times higher than traditional visual accuracy, with a maximum positioning accuracy of 0.1MM

technical parameter

Camera type scanning speed

Wide scan camera 150-600MM/S

Map matching method

File Map Template Matching

Deformation processing motion platform

Supports deformation matching, sub-pixel detection algorithm supports UV flatbed machines, UV tape guides, and onepass printers

Matching accuracy supports motherboard types

0.1MM-0.3MM industry mainstream motherboards can support

Graphics format resolution

300DPI/600DPI supports PRN files

Camera features: Wide scan camera

1. Compact installation structure, stable light source, and flexible splicing

2. Ultra clear image output

3. Overcoming the distortion limitations of traditional cameras

4. Flexible definition of scanning width and unlimited scanning length

5. Supports multiple image categories for output, including black and white, infrared, and full-color

6. Suitable for various industries, such as UV printing, 3C electronics, 5G products, clothing, shoe materials, etc

Product Overview:

We provide a wide scanning+visual positioning printing system to provide a complete set of process solutions for the UV printer automation industry, handicrafts, badges, accessories, digital products, shoe materials, clothing, and other fields.

Finished product display
